DeepsetFileUploader

Use DeepsetFileUploader to send files from your pipeline run to Haystack Platform temporary file storage and return stable references (file_id and file_name) you can expose as pipeline output so users can download those files from the product.

Key Features

• Uploads files generated during a pipeline run to the platform's temporary storage
• Returns stable file_id and file_name references for each uploaded file
• Accepts local file paths, Path objects, or in-memory ByteStream objects
• Uses environment variables for authentication — no credentials in pipeline YAML
• Works as a handoff step between file-generating components and downloadable pipeline outputs

Configuration

For DeepsetFileUploader to work, create the following secrets in the Haystack Platform workspace or organization where you want to use the component:

• Secret name: DEEPSET_API_URL, secret value: base URL of the deepset API. Set it to https://api.cloud.deepset.ai.
• Secret name: DEEPSET_API_KEY, secret value: the API key to connect to your Haystack Platform workspace or organization. For details on how to obtain it, see Generate API Keys.

Optionally, set the workspace name in the DEEPSET_WORKSPACE secret. If omitted, the component uses default.

For instructions on how to create secrets, see Add Secrets.

1. Drag the DeepsetFileUploader component onto the canvas from the Component Library.
2. Click the component to open the configuration panel.
3. The component has no parameters to configure in the panel. Authentication and workspace selection use the environment variables above.

Connections

DeepsetFileUploader can receive files from any component that produces a list of strings, paths, or ByteStream objects.

It can send the output files to the Output component, so users can download them from the platform.

Usage Example

Basic DeepsetFileUploader Configuration

This is the basic component configuration. The component has no parameters, so you just specify the component type and leave the init parameters empty.

components:
  file_uploader:
    type: deepset_cloud_custom_nodes.utils.deepset_file_uploader.DeepsetFileUploader
    init_parameters: {}

Pipeline Where Another Component Creates Files

This is an example of a pipeline where a custom component writes files to disk and exposes a list of paths that should become downloads.

  components:
    report_exporter:
      type: my_org.custom_nodes.report_exporter.ReportExporter
      init_parameters:
        output_format: csv
    file_uploader:
      type: deepset_cloud_custom_nodes.utils.deepset_file_uploader.DeepsetFileUploader
      init_parameters: {}
  connections:
    - sender: report_exporter.saved_paths
      receiver: file_uploader.files
  inputs:
    query:
      - "report_exporter.query"
  outputs:
    attachments: "file_uploader.files"
  max_runs_per_component: 100
  metadata: {}

ReportExporter is an example component that must output saved_paths as a list of strings (or paths). The pipeline output key attachments maps to the uploader's files list so the platform can treat them as downloadable file references.

Pipeline Where Files Are Supplied at Query Time

This is an example of a pipeline where files are supplied at query time. Users upload files to be translated and the pipeline returns the translated files. Note that the Input component is configured to accept files and query inputs, and the Output component is configured to output output_files and messages.

components:
  file_uploader:
    type: deepset_cloud_custom_nodes.utils.deepset_file_uploader.DeepsetFileUploader
    init_parameters: {}
  LLM:
    type: haystack.components.generators.chat.llm.LLM
    init_parameters:
      chat_generator:
        init_parameters:
          model: gpt-5.4
        type: haystack.components.generators.chat.openai_responses.OpenAIResponsesChatGenerator
      system_prompt: |-
        {% message role="system" %}
        You are a professional translator that translates files.
        {% endmessage %}
      user_prompt: |-
        {% message role="user" %}
        Translate the following {{ files }} into English.
        {% endmessage %}
      required_variables: "*"
      streaming_callback:

connections: []

max_runs_per_component: 100

metadata: {}

inputs:
  files:
  - file_uploader.files
  - LLM.files
  query:
  - LLM.messages

outputs:
  output_files: file_uploader.files
  messages: LLM.messages

Wire your client or Playground input schema so the pipeline receives a files value compatible with the uploader (paths or ByteStream-like payloads your platform sends).

Parameters

Inputs

Parameter	Type	Default	Description
files	List[Union[str, Path, ByteStream]]		Files to upload: local paths or in-memory streams. For paths, the file name is taken from the path. For ByteStream, set file_name in meta.

Outputs

Parameter	Type	Default	Description
files	List[Dict[str, str]]		One entry per uploaded file: file_id (platform ID) and file_name (original name).

Init Parameters

DeepsetFileUploader has no init parameters. Authentication and workspace selection use environment variables only.

Run Method Parameters

These are the parameters you can configure for the component's run() method. This means you can pass these parameters at query time through the API, in Playground, or when running a job. For details, see Modify Pipeline Parameters at Query Time.

Parameter	Type	Default	Description
files	List[Union[str, Path, ByteStream]]		Files to upload: paths or streams; for ByteStream, set file_name in meta.
