DeepsetVLMPDFToDocumentConverter

Convert PDF documents to text using a Vision Language Model (VLM).

Deprecation Notice

This component is deprecated. It will continue to work in your existing pipelines. You can replace it with the LLMDocumentContentExtractor component.

DeepsetVLMPDFToDocumentConverter uses a vision language model (VLM) to convert a screenshot of each PDF page into text based on your prompt. Use this converter with PDF files that have:

  • complex layouts
  • a mix of images and text
  • tables
  • handwritten text
  • figures

Through prompting, you can convert tables, images, or figures into a textual representation which can be useful for retrieval or for passing the resulting text to an LLM.

It helps to extract text in a natural reading order from PDF documents with complex layouts without having to implement custom post-processing code to keep a natural reading order.

Costs

This component can cause high costs with OpenAI or Amazon Bedrock if you use it to convert thousands of PDF pages. For OpenAI, one PDF page equals roughly 1,500 input tokens and a page equals roughly between 800 and 3,000 output tokens.

Configuration​

Key Features​

  • Uses a VLM to accurately convert complex PDF layouts, including tables, images, figures, and handwritten text.
  • Supports OpenAI models via the OpenAI API and Anthropic models via Amazon Bedrock.
  • Processes PDFs in parallel across files and pages for efficiency.
  • Fully customizable through prompt configuration.
  • Configurable detail level for image processing.
  • Supports retry logic with exponential backoff.

Configuration​

  1. Drag the DeepsetVLMPDFToDocumentConverter component onto the canvas from the Component Library.
  2. Click on the component to open the configuration panel.
  3. On the General tab:
    1. Select the VLM Provider: openai or bedrock.
    2. Enter the Model name (for example, gpt-4o).
    3. Edit the Prompt to control how the VLM extracts content.
  4. Go to the Advanced tab to configure max_workers_files, max_workers_pages, max_retries, backoff_factor, initial_backoff_time, detail, generator_kwargs, response_extraction_pattern, max_splits_per_page, progress_bar, and page_separator.

Connections​

DeepsetVLMPDFToDocumentConverter receives PDF sources from FileTypeRouter through its sources input. It outputs converted documents through its documents output, which you typically connect to DocumentJoiner or a preprocessor for further processing.

Usage Examples​

Basic Configuration​

  DeepsetVLMPDFToDocumentConverter:
    type: deepset_cloud_custom_nodes.converters.vlm_pdf_to_document.DeepsetVLMPDFToDocumentConverter
    init_parameters:
      vlm_provider: openai
      max_workers_files: 3
      max_workers_pages: 5
      max_retries: 3
      backoff_factor: 2
      initial_backoff_time: 30
      prompt: |-
        Extract the content from the document below.
        You need to extract the content exactly.
        Format everything as markdown.
        Make sure to retain the reading order of the document.

        **Headers- and Footers**
        Remove repeating page headers or footers that disrupt the reading order.
        Place letter heads that appear at the side of a document at the top of the page.


        **Images**
        Do not extract images, drawings or maps.
        Instead, add a caption that describes briefly what you see on the image.
        Enclose each image caption with [img-caption][/img-caption]

        **Tables**
        Make sure to format the table in markdown.
        Add a short caption below the table that describes the table's content.
        Enclose each table caption with [table-caption][/table-caption].
        The caption must be placed below the extracted table.

        **Forms**
        Reproduce checkbox selections with markdown.

        Go ahead and extract!

        Document:
      model: gpt-4o
      max_splits_per_page: 3
      detail: auto
      generator_kwargs:
        generation_kwargs:
          temperature: 0
          seed: 0
          max_tokens: 4000
        timeout: 120
      progress_bar: true
      page_separator: "\f"

This is an example index, where DeepsetVLMPDFToDocumentConverter receives PDFs from FileTypeRouter and then sends the converted files to DocumentJoiner:

components:
  file_classifier:
    type: haystack.components.routers.file_type_router.FileTypeRouter
    init_parameters:
      mime_types:
        - text/plain
        - application/pdf
        - text/markdown
        - text/html
        - application/vnd.openxmlformats-officedocument.wordprocessingml.document
        - application/vnd.openxmlformats-officedocument.presentationml.presentation
        - application/vnd.openxmlformats-officedocument.spreadsheetml.sheet
  text_converter:
    type: haystack.components.converters.txt.TextFileToDocument
    init_parameters:
      encoding: utf-8
  markdown_converter:
    type: haystack.components.converters.markdown.MarkdownToDocument
    init_parameters: {}
  html_converter:
    type: haystack.components.converters.html.HTMLToDocument
    init_parameters:
      extraction_kwargs:
        output_format: txt
        target_language: null
        include_tables: true
        include_links: false
  docx_converter:
    type: haystack.components.converters.docx.DOCXToDocument
    init_parameters: {}
  pptx_converter:
    type: haystack.components.converters.pptx.PPTXToDocument
    init_parameters: {}
  xlsx_converter:
    type: haystack.components.converters.XLSXToDocument
    init_parameters: {}
  joiner:
    type: haystack.components.joiners.document_joiner.DocumentJoiner
    init_parameters:
      join_mode: concatenate
  writer:
    type: haystack.components.writers.document_writer.DocumentWriter
    init_parameters:
      document_store:
        type: haystack_integrations.document_stores.opensearch.document_store.OpenSearchDocumentStore
        init_parameters:
          embedding_dim: 1024
          similarity: cosine
      policy: OVERWRITE
  DeepsetVLMPDFToDocumentConverter:
    type: deepset_cloud_custom_nodes.converters.vlm_pdf_to_document.DeepsetVLMPDFToDocumentConverter
    init_parameters:
      vlm_provider: openai
      max_workers_files: 3
      max_workers_pages: 5
      max_retries: 3
      backoff_factor: 2
      initial_backoff_time: 30
      prompt: |-
        Extract the content from the document below.
        You need to extract the content exactly.
        Format everything as markdown.
        Make sure to retain the reading order of the document.

        **Headers- and Footers**
        Remove repeating page headers or footers that disrupt the reading order.
        Place letter heads that appear at the side of a document at the top of the page.


        **Images**
        Do not extract images, drawings or maps.
        Instead, add a caption that describes briefly what you see on the image.
        Enclose each image caption with [img-caption][/img-caption]

        **Tables**
        Make sure to format the table in markdown.
        Add a short caption below the table that describes the table's content.
        Enclose each table caption with [table-caption][/table-caption].
        The caption must be placed below the extracted table.

        **Forms**
        Reproduce checkbox selections with markdown.

        Go ahead and extract!

        Document:
      model: gpt-4o
      max_splits_per_page: 3
      detail: auto
      generator_kwargs:
        generation_kwargs:
          temperature: 0
          seed: 0
          max_tokens: 4000
        timeout: 120
      response_extraction_pattern: null
      progress_bar: true
      page_separator: "\f"
connections:
  - sender: file_classifier.text/plain
    receiver: text_converter.sources
  - sender: file_classifier.text/markdown
    receiver: markdown_converter.sources
  - sender: file_classifier.text/html
    receiver: html_converter.sources
  - sender: file_classifier.application/vnd.openxmlformats-officedocument.wordprocessingml.document
    receiver: docx_converter.sources
  - sender: file_classifier.application/vnd.openxmlformats-officedocument.presentationml.presentation
    receiver: pptx_converter.sources
  - sender: file_classifier.application/vnd.openxmlformats-officedocument.spreadsheetml.sheet
    receiver: xlsx_converter.sources
  - sender: text_converter.documents
    receiver: joiner.documents
  - sender: markdown_converter.documents
    receiver: joiner.documents
  - sender: html_converter.documents
    receiver: joiner.documents
  - sender: docx_converter.documents
    receiver: joiner.documents
  - sender: pptx_converter.documents
    receiver: joiner.documents
  - sender: xlsx_converter.documents
    receiver: joiner.documents
  - sender: joiner.documents
    receiver: writer.documents
  - sender: file_classifier.application/pdf
    receiver: DeepsetVLMPDFToDocumentConverter.sources
  - sender: DeepsetVLMPDFToDocumentConverter.documents
    receiver: joiner.documents
max_runs_per_component: 100
metadata: {}
inputs:
  files:
    - file_classifier.sources

Parameters​

Inputs​

ParameterTypeDescription
sourcesList[Union[str, Path, ByteStream]]List of PDF sources to convert.
metaOptional[Union[Dict[str, Any], List[Dict[str, Any]]]]Optional metadata or list of metadata dictionaries.

Outputs​

ParameterTypeDescription
documentsList[Document]A list of converted documents.

Init Parameters​

These are the parameters you can configure in Pipeline Builder:

ParameterTypeDefaultDescription
vlm_providerLiteral['openai', 'bedrock']openaiType of VLM provider to use (openai or bedrock).
max_workers_filesint3Maximum number of threads for processing files.
max_workers_pagesint5Maximum number of threads for processing pages.
max_retriesint3Maximum number of retries for page-level extraction.
backoff_factorfloat2.0Factor for exponential backoff between retries.
initial_backoff_timefloat30.0Initial backoff time in seconds.
promptstrExtract the content from this document page. Format everything as markdown to recreate the layout as best as possible. Retain the natural reading order.Prompt to use for the VLM.
openai_api_keySecretSecret.from_env_var('OPENAI_API_KEY')OpenAI API key.
modelstrgpt-4oModel name to use with the generator.
max_splits_per_pageint3Maximum number of splits per page. Only applies when using openai as llm_provider.
detailLiteral['auto', 'high', 'low']autoDetail level for image processing. Choose high for the best results and low for the lowest inference costs.
generator_kwargsOptional[Dict[str, Any]]NoneAdditional keyword arguments for the generator. Check the Generator's documentation to learn about the parameters that you can pass.
response_extraction_patternOptional[str]NoneRegex pattern to extract text from the generator's response.
progress_barboolTrueWhether to display a progress bar.
page_separatorstr\x0cWhat string to use to separate pages.

Run Method Parameters​

These are the parameters you can configure for the component's run() method. This means you can pass these parameters at query time through the API, in Playground, or when running a job. For details, see Modify Pipeline Parameters at Query Time.

ParameterTypeDefaultDescription
sourcesList[Union[str, Path, ByteStream]]List of PDF sources to convert.
metaOptional[Union[Dict[str, Any], List[Dict[str, Any]]]]NoneOptional metadata or list of metadata dictionaries.
